TNC-100轻质逆向除渣器

产品概述

TNC-100型逆向轻质除渣器采用最新的反向净化技术，可清除蜡、泡沫塑料、热熔胶、乳胶、油脂等低密度材料中的轻量碎屑。TNC-100反向轻质除渣器在小直径内会有较长的停留时间，可以最大限度地分离接近纤维自身比重的非常小的污染物。进料浓度与传统轻质净化系统相同。

Production Overview

TNC-100 reverse light-weight centricleaner adopts the latest reverse purification technology to remove lightweight debris from all types of pulp and paper stock, such as wax, styrofoam, hot melt glues, latex, grease, and other low-density materials. It is featured longer stay time within a small diameter to maximize the separation of tiny contaminants, which is close to the specific gravity of the fiber itself. Feeding density is the same as in conventional lightweight cleaning system.

主要技术参数

单支通过量: 100 - 110 L/min

进浆浓度: 0.6 - 1.0%

良浆浓度: 0.8 -0.9%

进浆压力: 0.48 - 0.52 MPa

良浆压力: 0.06 - 0.10 MPa

体积排渣率: 40 -45%（相对进浆流量）

浆料温度要求: ≤ 60℃

Main Technical Parameters

Feeding flow: 100 - 110 L/min

Feeding density: 0.6 - 1.0%

Accepts density: 0.8 - 0.9%

Feeding pressure: 0.48 - 0.52 MPa

Accepts pressure: 0.06 - 0.10 MPa

Volume reject removal rate: 40 - 45％（relative to feeding flow）

Required pulp tempt.: ≤ 60℃
